Description
GXM-XDS-1 100X-400X Routine, Inverted Biological, Phase Contrast, Microscope LED – GX VALUE RANGE
A popular, great value for money routine and teaching grade,ย High Quality, Biological Inverted Phase Contrast Microscopeย comprising of:
Trinocular Head includinding a Camera Port with optional adapters to accept a wide variety of cameras, Pair 10X Widefield FN20 Eyepieces and a centering telescope for phase set-up, Inverted Quaduple Nosepiece, 10X Brightfield, 10X Phase, 25Xย Brightfield, 40Xย Brightfield, Plan Achromatic, Long working Distance Objectives (other phase objectives are available please see the accessores list below), ย Mechanical Stage equipped with a range of petri dish and culture flask holders, Coaxial Coarse/Fine Focus, Long Working Distance Centerable Phase Condenser with Phase Slider Inserts, Stable Stand, Bright Adjustable LED Light, Set of Filters including frosted, blue and green, Tools and a ย Large Range of Accessories.
The XDS-1 is a high quality invertedย biological microscope representingย very good value for money and isย designed to be affordable forย multiple user sites especially inย teaching and research laboratories.ย Each microscope is equipped with aย trinocular head ready for theย attachment of a digital camera. Theย microscopes include a full set of 4ย high quality long working distanceย plan achromatic objectivesย brightfield and phase objectives on aย quadruple objective turret.ย Specimens can placed on theย mechanical stage with a variety ofย specimen holders and ergonomicallyย positioned controls for XY stage andย focus control. The focussing tensionย can be adjusted and a focus lockย protects the objectives fromย damage. Illumination is providedย from an integral halogen lamp withย adjustable intensity, a long workingย distance condenser and phaseย contrast set.ย Options include a range of cameraย adapters, digital cameras, imageย analysis software, additionalย objectives and eyepieces.
This microscope is part of the GX Value Range – amazing on-line value.
Additional product information
| Brand and ID Number |
GX Microscopes Brand by GT Vision Ltd Product ID0456 |
| Eyepieces and Objectives |
Pair of 10X Widefield FN20 Eyepieces mounted in a 23.2mm internal diameter eyepiece tube. Centering telescope for phase set-up. Plan Achromatic Optics, 10X Brightfield, 10X Phase/brightfield 25X Brightfield, 40X Brightfield, Long working Distance Objectives. Objectives are mounted on a Quaduple revolving nosepiece. |
| Head |
Trinocular Head with camera port with interpupiliary adjustment and diopter adjustment for the eyepiece tubes. The camera port accepts camera adapters. There is a photo/eyepiece lever. Inclination 45ยฐ๏ผcamera output has 100% of light. Interpupillary distance adjustment range๏ผ48 ~75mm |
| Stand & Focus Mechanism |
High stability, robust, inverted microscope stand equipped with a coaxial coarse/fine focus mechanism with sample protection lock. |
| Stage and Condenser |
Double Layer, smooth, mechanical stage: size:200mm X 152mm๏ผmovement range: 75mm X 30mm , Stage plate holders included: circular petri /culture dishes๏ผ rectangular microtitre plates and culture flasks Long working distance phase contrast condenser with slider inserts. Centre adjustable. |
| Illumination |
Adjustable, bright LED Halogen illumination. Includes filter set. |
